202
APPX
Appendix 5 EMC, Low Voltage, and Machinery Directives
Measures to comply with the Machinery Directive
The Machinery Directive (2006/42/EC) requires that machinery satisfy the three pillars of safety: mechanical safety, electrical
safety, and worker safety.
This product is suitable for establishing safety functions for general industrial machinery and complies with the Machinery
Directive (2006/42/EC). Before using this product, please read this manual, the relevant manuals, and the safety standards
carefully and pay full attention to safety to handle the product correctly.
The descriptions are based on the requirements of the Machinery Directive and the harmonized standards. However, they do
not guarantee that the entire machinery constructed according to the descriptions complies with the Machinery Directive. The
manufacturer of the machinery must determine the testing method for compliance and declare conformity to the Machinery
Directive.
Standard: EN61000-6-7: 2015
*1 The module is an open-type device (a device designed to be housed in other equipment) and must be installed inside a conductive
control panel. The tests were conducted with the module installed in a control panel.
Test item Test description Value specified in standard
EN61000-4-2
EN61000-6-7
Electrostatic discharge immunity
*1
Immunity test in which static electricity is applied to
the cabinet of the equipment
8kV Contact discharge
EN61000-4-3
EN61000-6-7
Radiated, radio-frequency, electromagnetic
field immunity
*1
Immunity test in which electric fields are irradiated
to the product
80% AM modulation @1kHz
• 80 to 1000MHz: 20V/m
• 1.4 to 2.0GHz: 10V/m
• 2.0 to 6.0GHz: 3V/m
• 84.000, 137 to 174, 219.500, 380 to 400, 420 to 470,
698 to 960MHz: 20V/m
• 1.24 to 1.30, 1.428 to 2.0GHz: 10V/m
• 2.0 to 2.7, 3.3 to 3.6, 5.15 to 5.925GHz: 3Vm
EN61000-4-4
Fast transient burst immunity
*1
Immunity test in which burst noise is applied to the
power supply line and signal line
• AC main power line: 4kV
• DC main power line: 2kV
• I/O power, DC I/O and communication lines: 2kV
EN61000-4-5
EN61000-6-7
Surge immunity
*1
Immunity test in which lightning surge is applied to
the power supply line and signal line
• AC power line: 4kV CM, 2kV DM
• DC I/O Power, DC I/O, communication lines: 2kV CM
EN61000-4-6
EN61000-6-7
Conducted RF immunity
*1
Immunity test in which high frequency noise is
applied to the power supply line and signal line
80% AM modulation @1kHz
• 0.15 to 80MHz: 20V
• 3.39, 6.780, 13.560, 27.120, 40.680MHz: 20V
EN61000-4-11
Voltage dips and interruption immunity
*1
Immunity test in which power supply voltage is
momentarily interrupted
• 0%, 1 period, starting at zero crossing
• 0%, 250/300 periods (50/60Hz)
• 40%, 10/12 periods (50/60Hz)
• 70%, 25/30 periods (50/60Hz)
EN61000-4-6-16
EN61000-6-7
Conducted common-mode voltage immunity
*1
Immunity test in which common-mode noise is
applied to the power lines and signal lines
• 1.5 to 15kHz: 1 to 10V
• 15 to 150kHz: 10V
• 16.7, 50, 60, 150, 180Hz: 10V (continuously)
• 16.7, 50, 60Hz: 100V for short period of time (1s)
To Next Page
