APPX
Appendix 1 Safety Remote I/O Signals
159
A
List of safety remote I/O signals
Do not use any "Use prohibited" safety remote I/O signals. If any of the signals are used, correct operation of
the module cannot be guaranteed.
NZ2GFSS2-32D-S1
■Safety remote input (SA\X)
*1 Use this signal when "Operation setting of external power supply voltage error detection" is set to "2: Continue safety communication
(With output interlock)".
Signal direction: Safety remote I/O module  Master station
Device No. Name
SA\X0 Safety input signal X0
SA\X1 Safety input signal X1
SA\X2 Safety input signal X2
SA\X3 Safety input signal X3
SA\X4 Safety input signal X4
SA\X5 Safety input signal X5
SA\X6 Safety input signal X6
SA\X7 Safety input signal X7
SA\X8 Safety input signal X8
SA\X9 Safety input signal X9
SA\XA Safety input signal XA
SA\XB Safety input signal XB
SA\XC Safety input signal XC
SA\XD Safety input signal XD
SA\XE Safety input signal XE
SA\XF Safety input signal XF
SA\X10 Safety input signal X10
SA\X11 Safety input signal X11
SA\X12 Safety input signal X12
SA\X13 Safety input signal X13
SA\X14 Safety input signal X14
SA\X15 Safety input signal X15
SA\X16 Safety input signal X16
SA\X17 Safety input signal X17
SA\X18 Safety input signal X18
SA\X19 Safety input signal X19
SA\X1A Safety input signal X1A
SA\X1B Safety input signal X1B
SA\X1C Safety input signal X1C
SA\X1D Safety input signal X1D
SA\X1E Safety input signal X1E
SA\X1F Safety input signal X1F
SA\X20 to SA\X2C Use prohibited
SA\X2D External power supply status
SA\X2E Safety output control READY
SA\X2F Safety output control initial processing completion flag
*1
