1 PRODUCT LINEUP
13
1
1 PRODUCT LINEUP
Input module
Output module
I/O combined module
For applicable products, refer to the following.
Page 46 Applicable products
Module name Input specifications Module power
supply current
Weight Model Reference
DC input module Negative
common type
Spring clamp terminal block
24VDC, 32 points
230mA 0.45kg NZ2GFSS2-32D-S1 Page 20 NZ2GFSS2-32D-S1
type main input module
Spring clamp terminal block
24VDC, 8 points
150mA 0.25kg NZ2GFSS2-8D-S1 Page 24 NZ2GFSS2-8D-S1
type main input module
Module name Output specifications Module power
supply current
Weight Model Reference
Transistor output
module
Source type Spring clamp terminal block
24VDC, 0.5A/1 point, 8
points
160mA 0.25kg NZ2GFSS2-8TE-S1 Page 27 NZ2GFSS2-8TE-S1
type main output module
Module name Input
specifications
Output
specifications
Module power
supply current
Weight Model Reference
DC input, transistor
output module
• Input part: Negative
common type
• Output part: Source
type
Spring clamp
terminal block
24VDC, 8 points
Spring clamp
terminal block
24VDC, 0.5A/1
point, 8 points
160mA 0.25kg NZ2GFSS
2-16DTE-
S1
Page 30 NZ2GFSS2-
16DTE-S1 type main
I/O combined module
