108
-
Control
'13•HM-T-193
9.0 [S] Service menus
Menu 9.1.0 [S] Heat pump settings
Settings for outdoor unit are made in the sub-menus to this
menu.
Menu 9.1.1 [S] DM start heating
Degree minute setting for start of heat pump, heating.
Setting range: -120 – 0
Default value: -60
Menu 9.1.2 [S] DM start cooling
Degree minute setting for start of heat pump, cooling.
Setting range: 0 – 120
Default value: 60
Menu 9.1.3 [S] Stop Temp. heat low
Lowest limit of the heat pump’s working range during heating.
It stops below this outdoor air temperature.
The heat pump is permitted to start again when the outdoor air
temperature increases by two degrees above the set value.
Setting range: -25 – 43 °C
Default value: -25 °C
Menu 9.1.4 [S] Stop Temp. heat high
Highest limit of the heat pump’s working range during heating.
It stops above this outdoor air temperature.
The heat pump is permitted to start again when the outdoor air
temperature decreases by two degrees below the set value.
Setting range: -25 – 43 °C
Default value: 43 °C
Menu 9.1.5 [S] Stop temp. cool low
Lowest limit of the heat pump’s working range during cooling.
It stops below this outdoor air temperature.
The heat pump is permitted to start again when the outdoor air
temperature increases by two degrees above the set value.
Setting range: 10 – 43 °C
Default value: 10 °C
Menu 9.1.6 [S] Stop temp. cool high
Highest limit of the heat pump’s working range during cooling.
It stops above this outdoor air temperature.
The heat pump is permitted to start again when the outdoor air
temperature decreases by two degrees below the set value.
Setting range: 10 – 43 °C
Default value: 43 °C
Menu 9.1.7 [S] Time bet. starts
Minimum time interval in minutes between compressor starts
in the heat pump.
Setting range: 0 – 60 min
Default value: 0 min
Menu 9.1.8 [S] Min CompFreq act/set
Select the min compressor frequency here. Both actual and set
values are shown.
Menu 9.1.9 [S] Max CompFreq act/set
Select here the max limit for the compressor. Both actual and
set values are shown.
Menu 9.1.10 [S] OU Cur. heat act/max
The phase current to outdoor unit
is shown and the highest
permitted current in heating mode can be set here.
Menu 9.1.11 [S] OU Cur. cool act/max
The phase current to outdoor unit is shown and the highest
permitted current in cooling mode can be set here.
Menu 9.1.12 [S] Tank defrost Temp.
If the system is colder than the set value during defrosting,
connecting to HW. If HW is colder, the electric heater starts.
Menu 9.1.13 [S] Return
Return to Menu 9.1.0.
Menu 9.2.0 [S] Add. heat settings
Settings regarding additional heat, shunt in indoor unit and any
extra shunt can be made in the sub-menus to this menu.
Menu 9.2.1 [S] DM start add. heat
The degree minute deficit to activate additional heat supply is
set here.
Setting range: -1000 – -30
Default value: -400
Setting range: 20 – 30 °C
Default value: 20 °C
Menu 9.2.2 [S] Time factor
The time factor of the immersion heater since first start up is
shown here. The value is saved and is not reset even when the
system is switched off using the main power switch.
Menu 9.2.3 [S] Docking type
No function.
Control
FDCW71 FDCW100 FDCW140
Setting range (Hz) 20 – 86 20 – 80 20 – 77
Default value (Hz) 20 20 20
FDCW71 FDCW100 FDCW140
Setting range (Hz) 20 – 118 25 – 85 20 – 120
Default value (Hz) 118 85 120
FDCW71 FDCW100 FDCW140
Setting range (A) 7 – 16 7 – 17 7 – 25
Default value (A) 15 15 24
FDCW71 FDCW100 FDCW140
Setting range (A) 7 – 15 7 – 17 7 – 23
Default value (A) 14 15 22
#
