System description
'13 • HM-T-193
General
Explanation
External
Mixing valveQN11
Shuttle valve for heating/coolingQN12
Non-return valveRM
Expansion vesselCM1
Heating system 2EP21
Circulation pump, external 1GP10
External controlKF
Flow indicatorPG1
Room sensor MH-RG 10 (accessory)MH-RG10
Buffer vessel (accessory)CP1
Safety valveFL1
Mixer valve, HWFQ1
Indoor unit
Temperature sensor, outdoor air (external)BT1
Temperature sensor, supplyBT2
Temperature sensor, heat exch. in (Twin)BT3
Temperature sensor, tank waterBT6
Temperature sensor, heat exch. out (Twout)BT12
Temperature sensor, liguid pipe (Thi-L)BT15
Temperature sensor, immersion heaterBT19
Temperature sensor, external heat sourceBT24
Thermostat, standby modeBT30
Temperature limiterFD1
High pressure sensorBP4
Mixing valveQN11
Reversing valve, hot waterQM30
Reversing valve, climate systemQM31
Filter dryer (refrigerant)HS1
Immersion heaterEB1
Heat exchangerEP2
Circulation pump, climate systemGP1
Particle (water)HQ1
Safety valve, tankFL2
Pressure gaugeBP5
Sanitary cold water inletCW
Sanitary hot water outletHW
Outdoor unit
Temperature sensor, outdoor airTho-A
Temperature sensor, hot gasTho-D
Temperature sensor, heat exchanger outTho-R1
Temperature sensor, heat exchanger, inTho-R2
Temperature sensor, suction gasTho-S
Low pressure sensorLPT
High pressure switch63H1
Current sensorCT
Expansion valve, coolingEEV-C
Expansion valve, heatingEEV-H
Fan motorFMo1
4-way valve20S
Compressor motorCM
Valve, solenoidSV
General
Optional parts
Optional 1 : Room sensor
To control the system operation by room temperature. See page 48
Optional 4 : HW parts
To manage outlet water temperture. See page 69
Optional 5 : Extra system volume
To ensure minimum required water volume in heating system.
See page 66
Optional 6 : Flow relief valve
To ensure water flow in case thermostats are installed on
radiators. See page 66
Optional 7 : Extra system pump
To ensure water flow in case pressure drop of heating system is
big. See page 68
Optional 8 : Extra system volume only with floor heating / cooling
To ensure minimum required water volume especially for under-
floor system. See page 66
Optional 9 : Non-return valve
To ensure water flow in the extra system pump during HW opera-
tion. See page 68
