Service
-
193
-
'13 • HM-T-193
Fan and fan motor (FMo1)
6.
Remove tapes and fan cable
7. Release 2 metal clamps
8. Loosen 4 screws and remove
fan motor
Compressor (CM)
1.
Untie the strings and remove
the outer insulation
Fan cable
4 screws
Outer Insulation
Tapes
Control box
2 metal clamps
FDCW71VNX
Component replacement
