Installation
'13 • HM-T-193
Indoor unit installation
General information
Transport and storage
Indoor unit can be transported vertically and must be stored
vertically and in dry conditions. HMS140VA and HMS140V can
be transported and stored vertically or holizontally.
Supplied components
HMA100V, HMA100VM, HMS140VA, HMS140V
The enclosed kit is located behind the front service cover in indoor unit.
Assembly
■ Itisrecommendedthatindoorunit isinstalledinaroom
withexistingoordrainage,mostsuitablyinautilityroom
or boiler room.
■ Thesu
rfacemust befirm,preferablya concreteflooror
foundation.Forwallmountunit,thesurfacemustbef irm,
f latandvertical,preferablyaconcretewall.
■ Installindoorunitwithitsbacktoanoutsidewall,ideally
in a room where noise does not matter. If this is not
possible,avoidplacingit
againstawallbehindabedroom
or other room where noise may be a problem.
■ Floo
r standing indoor unit can be aligned using the
adjustable feet.
■ Rout
epipes sotheyarenotfixedtoaninternalwallthat
backs on to a bedroom or living room.
Indoor unit installation
■ ForHMA100VandHMA100VM,besurethat sufficinet
service space is provided as shown in following page.
■ ForHM
S140VAandHMS140V,be sure to connect a tank
on HW port even if HW application is not used.
■ F
orHM
S140VAandHMS140V,install tank unit and its
pipings to indoor unit indoors in order to avoid icing.
■ F
or HT
30, MT300 and MT500, besurethatsufficinet
service space is provided as shown in the following page.
HMA100V, HMA100VM
HMS140V, HMS140VA
To Next Page
