Mitsubishi Heavy Industries HMS140VA1 User Manual

For Home Owners
-
45
-
'13 • HM-T-193
How to use front panel
All the most common settings are made from panel such as
comfortetc.thatyourequiretheheatpumpsystemtofull.
Inordertomakefulluseofit,certainbasicsettingsmusthave
been made (see page 47) and installation should be carried out
according to the instructions.
Menu 1.0 (the temperature in the water heater) is
normally shown on the display.
The plus and minus buttons and the enter button are
used to scroll through the menu system as well as to
change the set value in some menus.
Menu types (Menu 8.1.1)
Control is classified into different menu types depending on
how “deep” into the controls you need to go.
■ Normal[N]: T
he settings you as a customer
often need.
■ Extended[U]: S
hows alldetailed menusexcept
the service menus.
■ Service[S]:
Showsallmenus.
Changing of menu type is done from Menu 8.1.1
Quick movement
Toquicklyreturntothemainmenufromasubmenu,press
thefollowingbutton:
Key lock
Akeylockcanbeactivatedinthemainmenusbysimultaneously
pressing the
and the buttons.Thekeysymbolwill
then be shown on the display.
Thesameprocedureisusedtodeactivatethekeylock.
Language setting (Menu 8.1.2)
Language used in the display can be chosen in Menu 8.1.2.
Front panel, indoor module
