'13 • HM-T-193
Technical data
Specifications
Indoor model
HMA100V1
HMA100V2
HMA100VM1
HMA100V1
HMA100V2
HMA100VM1
HMS140VA1
HMS140VA2
HMS140V1
HMS140V2
Outdoor model FDCW71VNX-A FDCW100VNX-A FDCW140VNX-A
Power source
1 phase 230V 50Hz/
3 phase 400V 50Hz
3 phase 230V 50Hz
1 phase 230V 50Hz/
3 phase 400V 50Hz
3 phase 230V 50Hz
1 phase 230V 50Hz/
3 phase 400V 50Hz
Heating nominal capacity
condition 1 kW 8.0 (3.0 - 8.0) 9.0 (3.5 - 12.0) 16.5 (5.8 - 16.5)
condition 2 kW 8.3 (2.0 - 8.3) 9.2 (3.5 - 10.5) 16.5 (4.2 - 17.2)
condition 3 kW 5.9 7
.2 12.0
Heating power consumption
condition 1 kW 2.40 2.50 4.98
condition 2 kW 2.03 2.0
7 3.93
condition 3 kW 1.
73 1.97 3.61
COP
condition 1 3.33 3.60 3.31
condition 2 4.09 4.28 4.20
condition 3 3.41 3.65 3.32
Cooling nominal capacity
condition 1
kW 7.1 (2.0 - 7.1) 8.0 (3.0 - 9.0) 1
1.8 (3.1 - 11.8) —
condition 2 kW 10.7 (2.7
- 10.7) 11.0 (3.3 - 12.0) 16.5 (5.2 - 16.5)
Cooling power consumption
condition 1 kW 2.65 2.85 4.45 —
condition 2 kW 3.19 3.04 4.36 4.60
EER
condition 1 2.68 2.81 2.65 —
condition 2 3.35 3.62 3.78 3.59
Tapping capacity
12liter/min
liter 270 27
0 —
16liter/min liter 200 200 —
Operation range
(Outdoor temperature)
heating -20 - 43
cooling 15 - 43
Operation range
(Water temperature)
heating 25 - 58 (65 with immersion heater)
cooling 7 - 25 7 - 25 18-25
System water ow l/s 0.19 - 0.38 0.24 - 0.57 0.40 - 0.
79
Max current A
44/
16
30
44/
16
30
50/
25
Recommended fuse rating A
50/
16
32
50/
16
32
63/
25
Starting current A 5
Deviation, incoming supply -15 - +10%
Max refrigerant pipe length m 30
Max height dif
ference between IU and OU m 7
Height mm 1760 (+20 - 50mm, adjustable feet) 1004
Width mm 600 513
Depth mm 650 360
W
eight (without water in the system) kg 140 60
Color White
IP Grade IP21
Immersion heater 9kW 4steps (2, 4, 6, 9) —
Output W 9-63 (variable speed) 9-110 (variable speed)
Max available external pressure bar 0.57 0.61
Max ow l/s 0.54 0.78
Flow at 20kPa pressure drop l/s 0.45 0.67
Emergency mode thermostat
℃
35/45 —
Temperature limiter
℃
98(-8) —
Safety valve bar 2.5 —
V
olume total liter 270 ±5% —
Volume hot water coil liter 14 —
Material hot water coil Stainless steel —
Max pressure, tank bar 2.5 —
Max pressure, hot water coil bar 10.0 —
W
ater quality, domestic hot water
≦
EU directive no 98/83/EF —
Volume expansion vessel liter — 18
Ambient temperature, indoor module
℃
5-35, RH95%
Dimensions, climate system pipe mm 22 28
Dimensions, hot water pipe mm 22 —
Water pipe connection Compression ttings
External heat source connection ISO 228/1 G1 —
