Motorola APX 7500 O5 User Manual

General Radio Operation
English
28
Making a Talkgroup Call
To make a call to a group of users, your radio must be
configured as part of that talkgroup.
Procedure:
1 < or > to TGRP. The display shows the last-selected
talkgroup.
OR
Rotate the Channel Knob to select the channel with the
desired talkgroup.
2 Hold the radio vertically 1 to 2 inches (2.5 to 5.0 cm) from
your mouth.
3 Press the PTT button to make the call.
4 ASTRO Conventional Only:
The LED lights up solid red. The display shows the
talkgroup alias or ID.
OR
Trunking Only:
The LED lights up solid red.
5 Speak clearly into the microphone.
6 Release the PTT button to listen.
See Using the Talkgroup Call Feature (Conventional
Operation Only) on page 34 for details on setting a Talkgroup
Making a Private Call (Trunking, Digital Mode
Only)
This feature allows you to send an individual Call Alert page if
there is no answer from the target radio. Your radio must be
preprogrammed to allow you to use this feature.
Procedure:
Press the preprogrammed Quick Access (One-Touch)
Enhanced Private Call button to dial the preprogrammed ID
and proceed to Step 5.
OR
Follow the procedure below.
1 < or > to CALL.
2 Press the Menu Select button directly below CALL. The
LED lights up solid red. The display shows the last
transmitted or received ID.
3 Press the Menu Select button directly below CNTS to scroll
through and select the required ID.
OR
Press the Menu Select button directly below LIST to go to
the first number of the call list.
OR
< or > to the required ID.
OR
Use the keypad to enter the required ID.
4 Press the PTT button to start the Private Call.

