NOTICE:
Ensure the switch on the cloning cable is set to Legacy.
During the cloning process, no power is applied to the SUC. The batteries cannot be
charged. A data communication is established between the two radios.
3 Turn on the target radio and place it into one of the SUC.
4 To power the source radio, press and hold the PTT button and the - button simultaneously while
turning on the radio until you hear the cloning tone.
5 To start the cloning process, place the source radio in its SUC with an audio accessory, then
press and release the Menu button.
If successful, the source radio sounds a good key chirp tone.
If unsuccessful, the source radio sounds bonk tone.
The tone sounds for no more than five seconds.
6 Turn the radios off and on to bring the radios to the user mode by exiting the clone mode when
the cloning process is completed.
NOTICE: When the radio is in clone mode, the Auto Power Off feature is not applicable.
Cloning Radios using the Multi-Unit Charger
Prerequisites:
•
A fully charged battery on each radio.
•
CLP Series Multi-Unit Charger (MUC).
• Both radios are turned off.
• Source radio: Radio to be cloned.
• Target radio: Radio to which the configuration of the source radio is to be copied.
Procedure:
1 To put the source radio into clone mode, press and hold the source radio PTT button and the -
button simultaneously while turning on the radio until you hear the cloning tone.
2 Place the source radio into one of the charging pockets that has the CLONE label.
3 Turn on the target radio and place it in the pairing charging pocket that has the CLONE label
and start the cloning process.
4 To start the cloning process, press the Menu button on the source radio.
The source radio generates the start clone tone.
5 To activate the radio, turn off and on the radios when cloning process is completed.
6 To clone another radio, repeat step 3 to step 5.
7 To exit clone mode on the source radio, turn off the radio.
MN006181A01-AA
Radio Cloning
34
