Getting Started 1 - 9
SD/SDIO Card
To install an SD memory card or an SDIO card:
1. Press the red Power button to turn off the screen and place the mobile computer in suspend mode.
2. Loosen the two captive screws securing the SD card cover.
Figure 1-8
SD Card Cover Screw Removal
3. Remove the SD card cover.
Figure 1-9
SD Card Cover Removal
4. Insert the SD card into the SD card slot. Note the position of the notch on SD card.
NOTE Motorola neither sells nor supports 3
rd
party SDIO products integrated into the MC1000. Motorola is not
responsible for the 3
rd
party SDIO card in-country regulatory certification. Customers must contact directly
with the selected 3
rd
party SDIO card vendors to ensure the vendor has obtained all the required
regulatory certifications for the targeted countries.
