Accessories 3 - 7
6. Press F - TAB to select the Port Mode.
7. Use the scroll key to highlight USB Host Mode.
8. Press ENT.
After using the Ethernet cradle the MC1000 must be placed in USB Client mode if ActiveSync is required.
1. Press F - CTRL - F - ESC to launch the Start menu.
2. Use the scroll keys to select Settings - Control Panel.
3. Press ENT.
4. Use the scroll keys to select the USBConfig icon.
5. Press ENT.
6. Press F - TAB to select the Port Mode.
7. Use the scroll key to highlight USB Client Mode.
8. Press ENT.
Battery Charging
The Four Slot Ethernet cradle can charge up to four mobile computers simultaneously. The Li-ion battery charges
in approximately four hours. To charge the mobile computer:
1. Connect the Four Slot Ethernet cradle to a power source.
2. Firmly press the mobile computer into the mobile computer slot.
3. The mobile computer’s Charge LED indicates the mobile computer battery charging status.
4. When charging is completed, hold the cradle with one hand and lift the mobile computer out of the cradle with
the other hand.
LED Charge Indications
The charge LED shows the status of the battery charging in the mobile computer. The main battery usually charges
in less than four hours. See Table 3-1 on page 3-3 for charging status indications.
Speed LED
The green Speed LED lights to indicate that the transfer rate is 100 Mbps. When it is not lit it indicates that the
transfer rate is 10Mbps.
Link LED
The yellow Link LED blinks to indicate activity, or stays lit to indicate that a link is established. When it is not lit it
indicates that there is no link.
NOTE Re-chargeable AAA batteries do not charge in the mobile computer when the mobile computer is placed in the
Four Slot Ethernet cradle.
To charge the battery for your mobile device, battery and charger temperatures must be between +32° F and
+104° F (0° C to +40° C).
