Recommended Tools
The following tools may be needed while performing the disassembly and assembly
procedures.
• Cross-head screwdriver
• Parallel screwdriver
• Tweezers
• Pry tool (optional)
• Needle-nose pliers
• Diagonal pliers
• Heat gun (optional)
• Anti-static gloves
• Anti-static wrist strap (optional)
• Anti-static mat with grounding wire (optional)
Screw List
Please refer to the screw list below while proceeding the disassembly and assembly
of the computer.
Note: This screw list is for reference only and may vary from models to models. It
is highly recommended that users contact the authorized service center for further
assistance.
Component Screw Type Quantity
Top Bracket M3*4 4
Power Button M3*4 2
Antennas M3*4 4
Fan M2.5*4 2
Heat Sink M2.5*4 4
SSD Heat Sink M3*L3.5 2
(1 optional)
M2*L3.29 2
(1 optional)
Wireless Card M2*H4.78*L1.85+2.45+4mm 1
Hard Drive (optional) M3*4 4
Mainboard/Bottom Bracket M2.5*0.45,6.8mm,26.25+5mm 4
