34
Top Bracket
Top Bracket Disassembly
1. Release the top bracket ❶ by removing the screws ❷ that secure the top
bracket and the screws ❸ that secure the power button with a cross-head
screwdriver.
2. Remove the top bracket
❶ from the top cover ❹.
3
1
2
1 4
