Introduction
1-5
Quick Components Guide
Component Function Reference
DIMM1~3 Installing DIMM modules See p. 2-5~2-6
Socket 462 Installing CPU See p. 2-2~2-4
C_FAN1 Connecting to CPU FAN See p. 2-20
S_FAN1 Connecting to SYSTEM FAN See p. 2-20
ATX Power Supply Installing power supply See p. 2-7
JPW1 Connecting to 12V ATX power supply See p. 2-8
IDE1& IDE2 Connecting to IDE hard disk drives See p. 2-14
FDD1 Connecting to floppy disk drive See p. 2-13
USB2 Connecting to USB interfaces See p. 2-18
PCI Slot 1~5 Installing PCI expansion cards See p. 2-23
AGP Slot Installing AGP cards See p. 2-23
CNR Slot Installing CNR cards See p. 2-23
ISA Slot Installing ISA cards See p. 2-24
JMDM1 Connecting to modem module See p. 2-17
JWOL1 Connecting to LAN module See p. 2-17
JBAT1 Clearing CMOS data See p. 2-22
JFP1 Connecting to case See p. 2-15
J2 Connecting to IR modules See p. 2-18
J21 Connecting to D-Bracket™ See p. 2-21
J17 Setting CPU FSB clock See p. 2-4
