National Instruments NI PCI-6510 User Manual

3-24 | ni.com
Chapter 3 Digital I/O
63, 64, 65, 66, 67, 68, 69, 70 P3.<0..7> Input Data lines for port 3
71, 72, 73, 74 P3.COM Input Common lines for port 3
25, 75 NC — No connection
26, 27, 28, 29, 30, 31, 32, 33 P4.<0..7> Output Data lines for port 4
34 P4.COM (GND) Input Ground for port 4;
isolated from the
computer power supply
35, 36, 37 P4.VCC Input Power lines for port 4
76, 77, 78,79, 80, 81, 82, 83 P5.<0..7> Output Data lines for port 5
84 P5.COM (GND) Input Ground for port 5;
isolated from the
computer power supply
85, 86, 87 P5.VCC Input Power lines for port 5
38, 39, 40, 41, 42, 43, 44, 45 P6.<0..7> Output Data lines for port 6
46 P6.COM (GND) Input Ground for port 6;
isolated from the
computer power supply
47, 48, 49 P6.VCC Input Power lines for port 6
50 P6.+5V Output +5 V for port 6
88, 89, 90, 91, 92, 93, 94, 95 P7.<0..7> Output Data lines for port 7
96 P7.COM (GND) Input Ground for port 7;
isolated from the
computer power supply
97, 98, 99 P7.VCC Input Power lines for port 7
100 P7.+5V Output +5 V for port 7
Table 3-5. NI 6514 Signal Descriptions (Continued)
Pin Number Signal Name
Input or
Output
Signal Description
