National Instruments NI PCI-6510 User Manual

3-26 | ni.com
Chapter 3 Digital I/O
NI 6516 Signal Descriptions
NI 6517 Signal Descriptions
96 P7.COM (VCC) Input Power line for port 7
97, 98, 99 P7.GND Input Ground for port 7;
isolated from the
computer power supply
100 P7.+5V Output +5 V for port 7
Table 3-7. NI 6516 Signal Descriptions
Pin Number Signal Name
Input or
Output
Signal Description
1, 2, 3, 4, 20, 21, 22, 23 P0.<0..7> Output Data lines for port 0
6, 7, 8, 9, 24, 25, 26, 27 P1.<0..7> Output Data lines for port 1
10, 11, 12, 13, 29, 30, 31, 32 P2.<0..7> Output Data lines for port 2
15, 16, 17, 18, 33, 34, 35, 36 P3.<0..7> Output Data lines for port 3
5, 14, 28, 37 VCC Input Power lines for all
ports
19 COM (GND) Input Common line for all
ports
Table 3-8. NI 6517 Signal Descriptions
Pin Number Signal Name
Input or
Output
Signal Description
1, 2, 3, 4, 20, 21, 22, 23 P0.<0..7> Output Data lines for port 0
6, 7, 8, 9, 24, 25, 26, 27 P1.<0..7> Output Data lines for port 1
10, 11, 12, 13, 29, 30, 31, 32 P2.<0..7> Output Data lines for port 2
15, 16, 17, 18, 33, 34, 35, 36 P3.<0..7> Output Data lines for port 3
Table 3-6. NI 6515 Signal Descriptions (Continued)
Pin Number Signal Name
Input or
Output
Signal Description

National Instruments NI PCI-6510 Specifications

General

Brand	National Instruments
Model	NI PCI-6510
Category	I/O Systems
Language	English
