Planar-D1 / Compact-M2 R7
Technical data
Technical information
Frequency range 434.050 – 434.750 MHz
RF power < 10 mW
Typical working range ≤ 100 m
(depending on environmental conditions)
Frequency channel search, automatic –
Antenna Integrated
Typical response time of the control
commands
approx. 50 ms
Active/passive 2 s
LF modulation method GFSK
Data rate 9600 baud (bit / sec.)
Ø Current consumption approx. 60 mA
Prewarning time “Battery empty” approx. 15 minutes
Serial number mode
(service case, device replacement)
Input via key combination on the device
LC/TFT display 7-segment channel/status display
Energy saving function (standby)
Standard: after 60 min.
Optional: Setting according to customer requirements
(continuous operation possible)
Machine data
Ambient operating temperature -20 °C up to +70 °C
Weight 160 g
Dimensions (L x W x H) 124 mm x 56 mm x 37 mm
Case material Impact resistant, glass fiber reinforced polyamide
Status display
(7-segment, depending on the configuration)
1x (1-digit)
Equipment safety
CE certification Yes
Protection class IP65
Data security Addressing of each transmitter by unique bit combination
EMERGENCY STOP or STOP function Yes (sending stop telegrams for 2 sec.)
Power supply
Power supply 2x AA/LR6/Mignon battery or accu
Operating time Up to 30 hours
Loading form
Standard: Externally, via a separate charger
Option: via wall mounted charging cradle
Charger available for (UE) 110 VAC – 230 VAC, 12/24 VDC
Plug form AC (adapter set) EU, USA, JP, GB, AU
Plug form DC Car charger plug
Transmitter Planar-D1
