NEC MultiSync E658 User Manual

English - 24
Chapter 3 Connections
This Chapter Includes
>
"Wiring Diagram" on page 25
>
"Headphones Connection" on page 25
>
"Connecting to a Personal Computer" on page 26
>
"Connecting to a Media Device with HDMI" on page 27
>
"HDMI-CEC Command" on page 29
>
"Internal Video Sources" on page 30
>
"Media Player" on page 30
>
"Connecting a USB Device" on page 31
Before making connections
• Turn off the power of the monitor, the computer and the external equipment before connecting the monitor to the computer.
• Refertotheexternalsequipment’susermanualsforavailableconnectiontypesandinstructionsforeachpieceof
equipment.
NOTE • When the audio output connector of the connected audio device or computer is a stereo mini jack, use an audio
cable without a resistor.
• Using an audio cable with a built-in resistor may make it impossible to increase the volume or mute the sound.
• Werecommendturningoffthemonitor’smainpowerbeforeconnectingordisconnectingaUSBstoragedevice.
• Donotconnectordisconnectcableswhenthemonitor’smainpowerorotherexternalequipment’spoweris
turned on.
