NETGEAR CBVG834G User Manual

Wireless Cable Voice Gateway Model CBVG834G Adminstrators User Manual
Wireless Configuration 2-11
v1.0, February 2008
WPA2 (WiFi Protected Access 2)
To configure WPA2:
1. On the Wireless Settings page, select the Security Option WPA2.
2. Enter the Security Encryption (WPA2) settings.
These settings are required for communication and authentication from a Radius server. A
secondary Radius server can be configured, which is used if the primary Radius server fails.
• Primary Radius Server IP Address. The IP address of the Radius server. The default is
0.0.0.0
• Radius Port. Port number of the Radius Server. The default is 1812.
• Radius Key. This is shared between the gateway and the Radius Server during
authentication.
3. Click Apply to save your settings.
Figure 2-6
