GS700TS Smart Switch Software Administration Manual
Configuring Switching Settings 4-16
v1.0, June 2009
To remove a VLAN:
Note: Prior to deleting a VLAN, ensure all multicast group configuration entries associated with
the VLAN are deleted. Refer to “Multicast Group Configuration” for deleting multicast
group entries.
1. Click Switching > VLAN > Basic > VLAN Configuration. The Basic VLAN Configuration
screen displays.
2. Select the VLAN entry.
3. Click DELETE to remove the entry.
Advanced
The VLAN Advanced menu contains the following options:
• “VLAN Configuration”
• “VLAN Membership”
• “Port PVID Configuration”
VLAN Configuration
The Advanced VLAN Configuration screen provides information and parameters for configuring
and working with VLANs. The maximum number of active VLANs is 128.
To define VLAN properties:
1. Click Switching > VLAN > Advanced > VLAN Configuration. The Advanced VLAN
Configuration screen displays:
Figure 4-11
