GS700TS Smart Switch Software Administration Manual
2-3 Introduction to the Web Browser Interface
v1.0, June 2009
Work Area – Located on the right side of the NETGEAR GS700TS web browser interface and
marked as 3 in Figure 2-2. The Work Area contains device tables, general device information, and
configurable device parameters.
For further description of the functions, refer to the appropriate section of this manual:
• Chapter 3, “Managing System Settings” describes how to configure the System functions.
• Chapter 4, “Configuring Switching Settings” describes how to configure the Switch functions.
• Chapter 5, “Configuring QoS” describes how to configure QoS functions.
• Chapter 6, “Managing Security” describes how to configure Security functions.
• Chapter 7, “Monitoring the Switch” describes how to configure Monitoring functions.
• Chapter 8, “Maintenance” describes maintenance functions, such as firmware upgrade.
• Chapter 9, “Online Help” describes how to obtain online help and support.
Using the NETGEAR Web Management System Options
The GS700TS web browser interface provides the following options:
• Device Management Buttons – Provides an explanation of the management buttons in the
NETGEAR GS700TS Smart Switch.
• Informational Services – Provides access to informational services including technical
support, online help and device information.
• Using Screen and Table Options – Provides an explanation of specific GUI characteristics
and tables for configuring the device.
Device Management Buttons
The NETGEAR GS700TS Smart Switch web browser GUI management buttons allow network
managers to easily configure the device from remote locations. The management buttons are
shown below:
Table 2-1. Device Management Buttons
Button Name Description
ADD Adds information to tables or information windows.
APPLY Applies configured changes to the device.
CANCEL Cancels modifications to tables or information windows.
