GS700TS Smart Switch Software Administration Manual
Managing Security 6-33
v1.0, June 2009
3. Select the ACL Name from the list in the provided field.
4. Select the interfaces to bind to the selected ACL Name by one of the following methods.
a. Click on the port or LAG gold bar to display the associated interfaces, and then select the
interfaces to bind by clicking on the boxes below the interfaces.
or
b. Click on the port’s or LAG’s quick box to select all the associated interfaces.
5. Click APPLY to update the device.
Binding Table
To view the ACL Binding Table:
1. Click Security > ACL > Binding Table. The Binding Table screen displays:
The Binding Table screen contains the following fields:
Interface Binding Table
• Interface – Displays the interfaces for which the ACLs are bound.
• MAC ACL – Displays the MAC Based ACL bound to the interface.
• IPv4 ACL – Displays the IPv4 Based ACL bound to the interface.
• IPv6 ACL – Displays the IPv6 Based ACL bound to the interface.
Figure 6-21
