NETGEAR GS724TS - ProSafe 24 Port Gigabit Stackable Smart Switch User Manual

GS700TS Smart Switch Software Administration Manual
6-32 Managing Security
v1.0, June 2009
1. Click Security > ACL > IPv6 Rules. The IPv6 Rules screen displays.
2. Select the ACL Name from the list in the provided field.
3. Select the rule entry.
4. Click DELETE to remove the entry.
IPv6 Binding Configuration
The IPv6 Binding Configuration screen contains information for mapping ACLs to IPv6
interfaces. When an ACL is bound to an interface, all the ACE rules that have been defined are
applied to the selected interface. Whenever an ACL is assigned on a port, LAG or, VLAN, flows
from that ingress interface that do not match the ACL are matched to the default rule, which is
Drop unmatched packets.
To bind interfaces to an ACL:
1. Click Security > ACL > IPv6 Binding Configuration. The IPv6 Binding Configuration
screen displays:
The IPv6 Binding Configuration screen contains the following fields:
IPv6 Binding Configuration
• ACL Name – Select the ACL Name for viewing and modifying ACL bound interfaces.
Port Selection Table
• Port Number (1-XX) – Displays the bound and unbound ports on the device.
2. Select the interfaces for which the ACLs are bound.
Figure 6-20
