GS700TS Smart Switch Software Administration Manual
6-28 Managing Security
v1.0, June 2009
IPv4 Binding Configuration
The IPv4 Binding Configuration screen contains information for mapping ACLs to IPv4 interfaces.
When an ACL is bound to an interface, all the ACE rules that have been defined are applied to the
selected interface. Whenever an ACL is assigned on a port, LAG or, VLAN, flows from that ingress
interface that do not match the ACL are matched to the default rule, which is Drop unmatched
packets.
To bind IPv4 interfaces to an ACL:
1. Click Security > ACL > IPv4 Binding Configuration. The IPv4 Binding Configuration
screen displays:
The IPv4 Binding Configuration screen contains the following fields:
IPv4 Binding Configuration
• ACL Name – Select the ACL Name for viewing and modifying ACL bound interfaces.
Port Selection Table
• Select the interfaces for which the ACLs are bound.
2. Select the interfaces to which the ACLs are bound.
3. Select the ACL Name from the list in the provided field.
Figure 6-17
