GS700TS Smart Switch Software Administration Manual
4-21 Configuring Switching Settings
v1.0, June 2009
The Port PVID Configuration screen contains the following fields:
• Interface – Displays the interface (port number or LAG number) to which the PVID tag is
assigned.
• PVID – Enter the PVID value. The possible field range is 1-4093.
2. Select an interface.
3. Enter the PVID in the provided field in the first row.
4. Click APPLY to update the device.
Voice VLAN
Voice VLAN allows you to enhance VoIP service by configuring ports to carry IP Voice traffic
from IP phones on a specific VLAN. VoIP traffic has a preconfigured OUI prefix in the source
MAC address.
Network managers can configure VLANs on which voice IP traffic is forwarded. Non-VoIP traffic
is dropped from the Voice VLAN in auto Voice VLAN secure mode. Voice VLAN also provides
QoS to VoIP, ensuring that the quality of voice does not deteriorate if the IP traffic is received
unevenly. The system supports one Voice VLAN.
Figure 4-15
