(Continued)
DescriptionField
Enter a value from 0 to 7.Priority
Select the check box for a wired LAN port or WiFi port.
If your device is connected to an Ethernet port on the router, select the LAN port check box that
corresponds to the Ethernet port on the router to which the device is connected. If your device is
connected to your router’s WiFi network, select the WiFi check box that corresponds to the router’s WiFi
network to which the device is connected.
You must select at least one LAN port or WiFi port. You can select more than one port.
9.
Click the Add button.
The VLAN tag group is added.
10.
Click the Apply button.
Your settings are saved.
Custom Static Routes
Typically, you do not need to add static routes unless you use multiple routers or multiple
IP subnets on your network.
As an example of when a static route is needed, consider the following case:
•
Your main Internet access is through a cable modem to an ISP.
•
Your home network includes an ISDN router for connecting to the company where
you are employed. This router’s address on your LAN is 192.168.1.100.
•
Your company’s network address is 134.177.0.0.
When you set up your router, two implicit static routes were created. A default route
was created with your ISP as the gateway, and a second static route was created to your
local network for all 192.168.1.x addresses. With this configuration, if you try to access
a device on the 134.177.0.0 network, your router forwards your request to the ISP. The
ISP forwards your request to the company where you are employed, and the company
firewall is likely to deny the request.
In this case you must define a static route, telling your router to access 134.177.0.0
through the ISDN router at 192.168.1.100. Here is an example:
•
The Destination IP Address and IP Subnet Mask fields specify that this static route
applies to all 134.177.x.x addresses.
User Manual86Manage Network Settings
Nighthawk X6S AC3600 Tri-Band WiFi Router Model R7960P
