English – 23
13
TECHNICAL SPECIFICATIONS
All technical specications stated herein refer to an ambient temperature of 20° C (± 5° C). • Nice S.p.a. reserves the right to apply modica-
tions to products at any time when deemed necessary, maintaining the same intended use and functionality.
ROX600 ROX1000 ROX1000/V1
Type Electromechanical gear motor for the automatic movement of sliding gates for residential use, complete
with electronic control unit
Pinion Z 15; Modulus: 4; Pitch: 12.5 mm; Primitive diameter: 60 mm
Peak thrust 18 Nm 24 Nm 24 Nm
Nominal torque 9 Nm 9 Nm 12 Nm
Speed (no load) 11 m/min 11 m/min 13 m/min
Nominal torque speed 8.5 m/min 8.5 m/min 8.5 m/min
Operating cycles 20 cycles/hour 20 cycles/hour 25 cycles/hour
Maximum continuous operating
time
4 minutes
Nominal power supply 230 V - 50/60 Hz 230 V - 50/60 Hz 120 V - 60 Hz
Nominal power 300 W 350 W 350 W
Electrical isolation class 1 (a safety grounding system is required)
Flasher output For 1 asher 230V~ auto-intermittent (120V~ on V1 / version motor) (max 60W)
STOP input For NC contacts (a variation with respect to the closed state causes the command “STOP”).
Sbs input For NO contacts (closing of the contact causes the “STEP-BY-STEP” command)
PHOTO Input For NC contacts (a variation with respect to the closed state causes a manoeuvre
reversal during the closure due to the detection of the photocell beam interruption)
Radio AERIAL Input 52 Ω for RG58 or similar type of cable
Radio receiver Incorporated
Operating temperature -20°C ... 55°C
Protection class IP 44
Dimensions (mm) and weight 330 x 210 x 303 h; 11 kg
Integrated radio receiver
Type 4 channel receiver for incorporated radio command
Frequency 433.92MHz
Transmitter compatibility FLO, FLOR, O-CODE, HCS SMILO coding
Transmitters memorized Up to 100 if memorized in mode 1
Input impedance 52Ω
Sensitivity better than 0.5 µV
Range of the transmitters From 100 to 150 m, this distance can vary in the presence of obstacles and electro-magnetic
interference and is affected by the position of the receiving aerial
Outputs For commands as per tables 8 and 9 of paragraph 7.3 - Integrated radio receiver
Operating temperature -20°C ... 55°C
12
MAINTENANCE
To keep the system safe and ensure a long service life, it must be serviced regularly: at most every 6 months or after 20,000 movements since
the last service.
CAUTION! – The maintenance operations must be performed in strict compliance with the safety directions provided in this
manual and according to applicable legislation and standards.
01.
