Introduction
Parts of the Camera
The Camera Body
12 3
5
6
11
7
8
4
9
10
13
12
Lens cover closed
Under the
connector cover
1 Shutter-release button..............................30
2
Zoom control..................................................29
f : wide-angle.......................................29
g : telephoto ..........................................29
h : thumbnail playback ...................83
i : playback zoom..............................85
3
Power switch/power-on lamp
...................................................................... 26, 162
4 Built-in microphone (stereo)....111, 128
5 Flash......................................................................34
6
Self-timer lamp ..............................................37
AF-assist illuminator................................. 160
7 Lens......................................................... 175, 192
8 Lens cover......................................................173
9
Power connector cover (for
connection with an optional AC
Adapter) ..........................................................176
10 Eyelet for camera strap ................................7
11 Connector cover...................134, 138, 144
12 HDMI mini connector (Type C).........135
13
USB/audio/video output connector
..........................................................134, 138, 144
