Nikon CoolPix S70 User Manual

16
First Steps
First Steps
Inserting the Battery
Insert a Rechargeable Li-ion Battery EN-EL12 (supplied) into the camera.
• Charge the battery before the first use or when the battery is running low
(A 16).
1 Open the battery-chamber/memory card slot
cover.
Slide the cover latch to Y side (
1
) and open the cover
(
2
).
2 Insert the battery.
Confirm that the battery’s positive (+) and negative (–)
terminals are oriented correctly as shown on the label at
the battery chamber opening, and insert the battery.
Use the battery to push the orange battery latch up (
1
)
as the battery is inserted (
2
).
The battery latch will spring back into place when the
battery is fully inserted.
B Inserting the Battery
Inserting the battery upside down or backwards
could damage the camera. Be sure to check that the
battery is in the correct orientation.
3 Close the battery-chamber/memory card slot
cover.
Close the cover (
1
) and slide the cover latch (
2
) to Z
side.

Nikon CoolPix S70 Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	CCD
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	640 x 480, 1024 x 768, 2048 x 1536, 2592 x 1944, 3264 x 2448, 3968 x 2232, 4000 x 3000
Digital zoom	4 x
Optical zoom	5 x
Focal length range	3 - 30 mm
Interface	USB
Digital SLR	No
Power source	AC Adapter EH-68P
Dimensions (WxDxH)	96.5 x 20 x 60.5 mm
Focal length (35mm film equivalent)	28 - 140 mm
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200, 6400
Internal memory	20 MB
Compatible memory cards	sd, sdhc
Display diagonal	3.5 \
Vari-angle LCD display	Yes
Product color	Red
Battery type	EN-EL12
Battery life (CIPA standard)	200 shots
Focus adjustment	Auto

Weight and Dimensions

Depth	20 mm
Width	96.5 mm
Height	60.5 mm
Weight	140 g
