Nikon D610 User Manual

148
l
Flash Compensation
Flash compensation is used to alter flash output by from –3EV to +1EV in increments
of
1
/3 EV, changing the brightness of the main subject relative to the background.
Flash output can be increased to make the main subject appear brighter, or reduced
to prevent unwanted highlights or reflections.
Press the M (Y) button and rotate the sub-command
dial until the desired value is displayed in the control
panel.
In general, choose positive values to make the
main subject brighter, negative values to make it
darker.
At values other than ±0.0, a Y icon will be displayed
in the control panel and viewfinder after you release
the M (Y) button.
The current value for flash
compensation can be confirmed by pressing the
M (Y) button.
Normal flash output can be restored by setting flash
compensation to ±0.0.
Flash compensation is not
reset when the camera is turned off.
A Optional Flash Units
Flash compensation is also available with optional flash units that support the Nikon
Creative Lighting System (CLS). The SB-910, SB-900, SB-800, SB-700, and SB-600 also allow
flash compensation to be set using the controls on the flash unit; the value selected with the
flash unit is added to the value selected with the camera.
A See Also
For information on choosing the size of the increments available for flash compensation, see
Custom Setting b2 (EV steps for exposure cntrl, 0 224). For information on choosing how
flash and exposure compensation combine, see Custom Setting e4 (Exposure comp. for
flash, 0 240). For information on automatically varying flash level over a series of shots, see
page 153.
(P
,
S
,
A
, an
d
M
M
o
d
es
O
n
l
y
)
M (Y) button Sub-comman
d
dia
l
±0 EV
(M (Y ) button pressed)
–0.3 EV
+1.0 EV

Nikon D610 Specifications

General

Megapixel	24.3 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.7 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4016 pixels
Image sensor size (W x H)	35.9 x 24 mm
Still image resolution(s)	6016 x 4016, 4512 x 3008, 3008 x 2008\\r 3936 x 2624, 2944 x 1968, 1968 x 1312\\r 6016 x 3376, 4512 x 2528, 3008 x 1688\\r 3936 x 2224, 2944 x 1664, 1968 x 1112
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Contrast Detection Auto Focus, Multi Point Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2250, 2500, 3200, 4000, 5000, 6400
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	0.005 s
Power source type	Battery
Video resolutions	1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	MOV
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	1280x720@25fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps
Audio formats supported	LPCM
Memory slots	2
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Display diagonal	3.2 \
Display resolution (numeric)	921000 pixels
Magnification	0.7 x
Viewfinder type	Optical
USB version	2.0
Headphone outputs	1
HDMI connector type	Mini
Product color	Black
Eye relief	21 mm
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Direct sunlight, Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade
Camera playback	Highlights, Movie, Single image, Slide show
Self-timer delay	2, 5, 10, 20 s
Camera file system	DPOF, DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-3 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL15
Operating temperature (T-T)	0 - 40 °C
Cables included	USB

Weight and Dimensions

Depth	82 mm
Width	141 mm
Height	113 mm
Weight	760 g
Weight (including battery)	850 g
