Nikon D610 User Manual

248
U
Choose the role played by the depth-of-field preview button during movie live view.
The options available are the same as for Assign Fn button (0 247), except that the
default setting is Index marking.
Choose the role played by the A AE-L/AF-L button during movie live view.
The options
available are the same as for Assign Fn button (0 247), except that the default
setting is AE/AF lock.
Choose the role played by pressing the shutter-release button when 1 is selected
with the live view selector.
g2: Assign Preview Button
G button ➜ A Custom Settings menu
g3: Assign AE-L/AF-L Button
G button ➜ A Custom Settings menu
g4: Assign Shutter Button
G button ➜ A Custom Settings menu
Option Description
C Take photos
Press the shutter-release button all the way down to end movie recording
and take a photograph with an aspect ratio of 16 : 9 (for information on
image size, see page 63).
1 Record movies
Press the shutter-release button halfway to start movie live view. You can
then press the shutter-release button halfway to focus (autofocus mode
only) and press it all the way down to start or end recording. To end
movie live view, press the a button. The shutter-release button on an
optional remote cord (0 298) can be used to start movie live view and to
start and end movie recording; the optional ML-L3 remote control,
however, can not be used to record movies. In remote control (4) mode,
pressing the shutter-release button halfway does not start movie live
view, while pressing the shutter-release button on the remote control
releases the shutter to record a photograph and does not start or end
movie recording.
A Record Movies
When this option is selected, interval timer (0 164) is not available and the shutter-release
button can not be used during movie live view to record photographs, measure preset white
balance, or record image dust off reference data. Select Take photos to use these options.

Nikon D610 Specifications

General

Megapixel	24.3 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.7 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4016 pixels
Image sensor size (W x H)	35.9 x 24 mm
Still image resolution(s)	6016 x 4016, 4512 x 3008, 3008 x 2008\\r 3936 x 2624, 2944 x 1968, 1968 x 1312\\r 6016 x 3376, 4512 x 2528, 3008 x 1688\\r 3936 x 2224, 2944 x 1664, 1968 x 1112
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Contrast Detection Auto Focus, Multi Point Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2250, 2500, 3200, 4000, 5000, 6400
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	0.005 s
Power source type	Battery
Video resolutions	1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	MOV
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	1280x720@25fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps
Audio formats supported	LPCM
Memory slots	2
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Display diagonal	3.2 \
Display resolution (numeric)	921000 pixels
Magnification	0.7 x
Viewfinder type	Optical
USB version	2.0
Headphone outputs	1
HDMI connector type	Mini
Product color	Black
Eye relief	21 mm
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Direct sunlight, Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade
Camera playback	Highlights, Movie, Single image, Slide show
Self-timer delay	2, 5, 10, 20 s
Camera file system	DPOF, DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-3 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL15
Operating temperature (T-T)	0 - 40 °C
Cables included	USB

Weight and Dimensions

Depth	82 mm
Width	141 mm
Height	113 mm
Weight	760 g
Weight (including battery)	850 g
