245
U
This option controls the operation of the main and sub-command dials.
• Reverse rotation: Reverse the direction of rotation of the
command dials when they are used to make adjustments to
Exposure compensation and/or Shutter speed/aperture.
Highlight options and press the multi selector right to select
or deselect, then highlight Done and press J.
This setting
also applies to the command dials for the MB-D14.
• Change main/sub: If Off is selected, the main command dial
controls shutter speed and the sub-command dial controls
aperture.
Select On (Mode A) to use the main command dial
to select aperture in shooting mode A, On to use the main
command dial to select aperture in modes A and M and the
sub-command dial to select shutter speed in modes S and M.
This setting also applies to the command dials for the MB-D14.
• Aperture setting: If Sub-command dial is selected, aperture can only be adjusted
with the sub-command dial (or with the main command dial if On is selected for
Change main/sub).
If Aperture ring is selected, aperture can only be adjusted
with the lens aperture ring and the camera aperture display will show aperture in
increments of 1 EV (aperture for type G, E lenses is still set using the sub-command
dial).
Note that regardless of the setting chosen, the aperture ring must be used to
adjust aperture when a non-CPU lens is attached.
• Menus and playback: If Off is selected, the multi selector is used to choose the picture
displayed during full-frame playback, highlight thumbnails, and navigate menus.
If On or On (image review excluded) is selected, the main command dial can be
used to choose the picture displayed during full-frame playback, move the cursor
left or right during thumbnail playback, and move the menu highlight bar up or
down.
The sub-command dial is used to display additional photo information in
full-frame playback and to move the cursor up or down during thumbnail
playback.
Select On (image review excluded) to prevent the command dials from
being used for playback during image review.
While menus are displayed, rotating
the sub-command dial right displays the sub-menu for the selected option, while
rotating it left displays the previous menu.
To make a selection, press 2 or J.
f5: Customize Command Dials
G button ➜ A Custom Settings menu

Nikon D610 Specifications

General

Megapixel	24.3 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.7 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4016 pixels
Image sensor size (W x H)	35.9 x 24 mm
Still image resolution(s)	6016 x 4016, 4512 x 3008, 3008 x 2008\\r 3936 x 2624, 2944 x 1968, 1968 x 1312\\r 6016 x 3376, 4512 x 2528, 3008 x 1688\\r 3936 x 2224, 2944 x 1664, 1968 x 1112
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Contrast Detection Auto Focus, Multi Point Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2250, 2500, 3200, 4000, 5000, 6400
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	0.005 s
Power source type	Battery
Video resolutions	1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	MOV
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	1280x720@25fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps
Audio formats supported	LPCM
Memory slots	2
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Display diagonal	3.2 \
Display resolution (numeric)	921000 pixels
Magnification	0.7 x
Viewfinder type	Optical
USB version	2.0
Headphone outputs	1
HDMI connector type	Mini
Product color	Black
Eye relief	21 mm
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Direct sunlight, Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade
Camera playback	Highlights, Movie, Single image, Slide show
Self-timer delay	2, 5, 10, 20 s
Camera file system	DPOF, DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-3 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL15
Operating temperature (T-T)	0 - 40 °C
Cables included	USB

Weight and Dimensions

Depth	82 mm
Width	141 mm
Height	113 mm
Weight	760 g
Weight (including battery)	850 g
