Nikon D610 User Manual

222
U
This option controls how autofocus adjusts to sudden large changes in the distance
to the subject when AF-C is selected or continuous-servo autofocus is selected when
the camera is in AF-A mode for viewfinder photography (0 97).
Choose whether the active focus point is highlighted in red in the viewfinder.
Choose whether focus-point selection “wraps around” from one edge of the
viewfinder to another.
a3: Focus Tracking with Lock-On
G button ➜ A Custom Settings menu
Option Description
C 5 (Long)
When the distance to the subject changes abruptly, the camera waits for the
specified period before adjusting the distance to the subject.
This prevents
the camera from refocusing when the subject is briefly obscured by objects
passing through the frame.
( 4
D 3 (Normal)
) 2
E 1 (Short)
Off
The camera immediately adjusts focus when the distance to the subject
changes.
Use when photographing a series of subjects at varying distances in
quick succession.
a4: AF Point Illumination
G button ➜ A Custom Settings menu
Option Description
Auto
The selected focus point is automatically highlighted as needed to establish
contrast with the background.
On
The selected focus point is always highlighted, regardless of the brightness of
the background. Depending on the brightness of the background, the
selected focus point may be difficult to see.
Off
The selected focus point is not highlighted. The area outside the current crop
is shown in grey (0 90).
a5: Focus Point Wrap-Around
G button ➜ A Custom Settings menu
Option Description
Wrap
Focus-point selection “wraps around” from top to
bottom, bottom to top, right to left, and left to right,
so that, for example, pressing 2 when a focus point
at the right edge of the display is highlighted (q)
selects the corresponding focus point at the left
edge of the display (w).
No wrap
The focus-point display is bounded by the outermost focus points so that, for
example, pressing 2 when a focus point at the right edge of the display is
selected has no effect.
q
w

Nikon D610 Specifications

General

Megapixel	24.3 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.7 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4016 pixels
Image sensor size (W x H)	35.9 x 24 mm
Still image resolution(s)	6016 x 4016, 4512 x 3008, 3008 x 2008\\r 3936 x 2624, 2944 x 1968, 1968 x 1312\\r 6016 x 3376, 4512 x 2528, 3008 x 1688\\r 3936 x 2224, 2944 x 1664, 1968 x 1112
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Contrast Detection Auto Focus, Multi Point Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2250, 2500, 3200, 4000, 5000, 6400
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	0.005 s
Power source type	Battery
Video resolutions	1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	MOV
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	1280x720@25fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps
Audio formats supported	LPCM
Memory slots	2
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Display diagonal	3.2 \
Display resolution (numeric)	921000 pixels
Magnification	0.7 x
Viewfinder type	Optical
USB version	2.0
Headphone outputs	1
HDMI connector type	Mini
Product color	Black
Eye relief	21 mm
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Direct sunlight, Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade
Camera playback	Highlights, Movie, Single image, Slide show
Self-timer delay	2, 5, 10, 20 s
Camera file system	DPOF, DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-3 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL15
Operating temperature (T-T)	0 - 40 °C
Cables included	USB

Weight and Dimensions

Depth	82 mm
Width	141 mm
Height	113 mm
Weight	760 g
Weight (including battery)	850 g
