Nikon D610 User Manual

73
#
#
P, S, A, and M Modes
P, S, A, and M modes offer different degrees of control over shutter
speed and aperture.
A Lens Types
When using a CPU lens equipped with an aperture ring (0 287), lock the aperture ring at the
minimum aperture (highest f-number). Type G and E lenses are not equipped with an
aperture ring.
Non-CPU lenses can only be used in modes A (aperture-priority auto) and M (manual), when
aperture can only be adjusted using the lens aperture ring. Selecting any other mode
disables the shutter release.
A Non-CPU Lenses (0 285)
Use the lens aperture ring to adjust aperture. If the maximum
aperture of the lens has been specified using the Non-CPU lens
data item in setup menu (0 172) when a non-CPU lens is attached,
the current f-number will be displayed in the viewfinder and
control panel, rounded to the nearest full stop. Otherwise the
aperture displays will show only the number of stops (F, with
maximum aperture displayed as FA) and the f-number must be
read from the lens aperture ring.

Nikon D610 Specifications

General

Megapixel	24.3 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.7 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4016 pixels
Image sensor size (W x H)	35.9 x 24 mm
Still image resolution(s)	6016 x 4016, 4512 x 3008, 3008 x 2008\\r 3936 x 2624, 2944 x 1968, 1968 x 1312\\r 6016 x 3376, 4512 x 2528, 3008 x 1688\\r 3936 x 2224, 2944 x 1664, 1968 x 1112
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Contrast Detection Auto Focus, Multi Point Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2250, 2500, 3200, 4000, 5000, 6400
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	0.005 s
Power source type	Battery
Video resolutions	1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	MOV
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	1280x720@25fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps
Audio formats supported	LPCM
Memory slots	2
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Display diagonal	3.2 \
Display resolution (numeric)	921000 pixels
Magnification	0.7 x
Viewfinder type	Optical
USB version	2.0
Headphone outputs	1
HDMI connector type	Mini
Product color	Black
Eye relief	21 mm
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Direct sunlight, Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade
Camera playback	Highlights, Movie, Single image, Slide show
Self-timer delay	2, 5, 10, 20 s
Camera file system	DPOF, DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-3 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL15
Operating temperature (T-T)	0 - 40 °C
Cables included	USB

Weight and Dimensions

Depth	82 mm
Width	141 mm
Height	113 mm
Weight	760 g
Weight (including battery)	850 g
