300
n
Caring for the Camera
Storage
When the camera will not be used for an extended period, replace the monitor cover,
remove the battery, and store the battery in a cool, dry area with the terminal cover
in place.
To prevent mold or mildew, store the camera in a dry, well-ventilated area.
Do not store your camera with naphtha or camphor moth balls or in locations that:
are poorly ventilated or subject to humidities of over 60%
are next to equipment that produces strong electromagnetic fields, such as
televisions or radios
are exposed to temperatures above 50 °C (122 °F) or below –10 °C (14 °F)
Cleaning
Do not use alcohol, thinner, or other volatile chemicals.
Camera
body
Use a blower to remove dust and lint, then wipe gently with a soft, dry cloth.
After
using the camera at the beach or seaside, wipe off sand or salt with a cloth lightly
dampened in distilled water and dry thoroughly.
Important: Dust or other foreign
matter inside the camera may cause damage not covered under warranty.
Lens,
mirror, and
viewfinder
These glass elements are easily damaged.
Remove dust and lint with a blower.
If
using an aerosol blower, keep the can vertical to prevent the discharge of liquid.
To
remove fingerprints and other stains, apply a small amount of lens cleaner to a soft
cloth and clean with care.
Monitor
Remove dust and lint with a blower.
When removing fingerprints and other stains,
wipe the surface lightly with a soft cloth or chamois leather.
Do not apply pressure,
as this could result in damage or malfunction.
D Servicing the Camera and Accessories
The camera is a precision device and requires regular servicing.
Nikon recommends that the
camera be inspected by the original retailer or Nikon-authorized service representative once
every one to two years, and that it be serviced once every three to five years (note that fees
apply to these services).
Frequent inspection and servicing are particularly recommended if
the camera is used professionally.
Any accessories regularly used with the camera, such as
lenses or optional Speedlights, should be included when the camera is inspected or
serviced.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nikon D610 and is the answer not in the manual?

Nikon D610 Specifications

General IconGeneral
Megapixel24.3 MP
Camera typeSLR Camera Body
Sensor typeCMOS
Image stabilizerNo
Total megapixels24.7 MP
Image sensor size- \
Image formats supportedJPG, RAW
Maximum image resolution6016 x 4016 pixels
Image sensor size (W x H)35.9 x 24 mm
Still image resolution(s)6016 x 4016, 4512 x 3008, 3008 x 2008\\r 3936 x 2624, 2944 x 1968, 1968 x 1312\\r 6016 x 3376, 4512 x 2528, 3008 x 1688\\r 3936 x 2224, 2944 x 1664, 1968 x 1112
Optical zoom- x
Mounting typeBayonet
Focal length range- mm
Lens mount interfaceNikon F
Minimum aperture number-
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) lockYes
Auto Focus (AF) points39
Auto focusing (AF) modesContrast Detection Auto Focus, Multi Point Auto Focus, Single Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Spot
ISO sensitivity100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2250, 2500, 3200, 4000, 5000, 6400
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)6400
ISO sensitivity (min)100
Light exposure correction±5EV (1/2; 1/3 EV step)
Camera shutter typeElectronic
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed30 s
Flash modesAuto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed0.005 s
Power source typeBattery
Video resolutions1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate60 fps
Video formats supportedMOV
Maximum video resolution1920 x 1080 pixels
Resolution at capture speed1280x720@25fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps
Audio formats supportedLPCM
Memory slots2
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Maximum memory card size64 GB
Display diagonal3.2 \
Display resolution (numeric)921000 pixels
Magnification0.7 x
Viewfinder typeOptical
USB version2.0
Headphone outputs1
HDMI connector typeMini
Product colorBlack
Eye relief21 mm
Scene modesPortrait, Landscape (scenery)
Photo effectsBlack&White, Neutral, Vivid
White balanceDirect sunlight, Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade
Camera playbackHighlights, Movie, Single image, Slide show
Self-timer delay2, 5, 10, 20 s
Camera file systemDPOF, DCF 2.0, Exif 2.3
Diopter adjustment (D-D)-3 - 1
On Screen Display (OSD) languagesARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUS, SWE, THA, TUR, UKR
Battery typeEN-EL15
Operating temperature (T-T)0 - 40 °C
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Depth82 mm
Width141 mm
Height113 mm
Weight760 g
Weight (including battery)850 g
