Nikon D610 User Manual

320
n
Playback
NEF (RAW) image is not played back: Photo was taken at image quality of NEF + JPEG (0 93).
Can not view pictures recorded with other cameras: Pictures recorded with other makes of camera may
not be displayed correctly.
Message is displayed stating that no images are available for playback: Select All for Playback folder
(0 207).
“Tall” (portrait) orientation photos are displayed in “wide” (landscape) orientation:
• Select On for Rotate tall (0 212).
• Photo was taken with Off selected for Auto image rotation (0 254).
• Camera was pointed up or down when photo was taken (0 254).
• Photo is displayed in image review (0 212).
Can not delete picture:
• Picture is protected: remove protection (0 188).
• Memory card is locked (0 32).
Can not retouch picture: Photo can not be further edited with this camera (0 262).
Can not change print order:
• Memory card is full: delete pictures (0 36, 189).
• Memory card is locked (0 32).
Can not select photo for printing: Photo is in NEF (RAW) format.
Create JPEG copy using NEF (RAW)
processing or transfer to computer and print using ViewNX 2 (supplied) or Capture NX 2
(available separately).
Picture is not displayed on TV:
• Choose correct video mode (0 65) or output resolution (0 205).
• HDMI (0 204) cable is not correctly connected.
Camera does not respond to remote control for HDMI-CEC television:
• Select On for HDMI > Device control in the setup menu (0 205).
• Adjust HDMI-CEC settings for the television as described in documentation provided with
the device.
Can not transfer photos to computer: OS not compatible with camera or transfer software.
Use card
reader to copy photos to computer (0 193).
Photos are not displayed in Capture NX 2: Update to latest version (0 298).
Image Dust Off option in Capture NX 2 does not have desired effect: Image sensor cleaning changes the
position of dust on the low-pass filter.
Dust off reference data recorded before image sensor
cleaning is performed can not be used with photographs taken after image sensor cleaning is
performed. Dust off reference data recorded after image sensor cleaning is performed can not
be used with photographs taken before image sensor cleaning is performed (0 252).
Computer displays NEF (RAW) images differently from camera: Third-party software does not display
effects of Picture Controls, Active D-Lighting, or vignette control. Use ViewNX 2 (supplied) or
optional Nikon software such as Capture NX 2 (available separately).

Nikon D610 Specifications

General

Megapixel	24.3 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.7 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4016 pixels
Image sensor size (W x H)	35.9 x 24 mm
Still image resolution(s)	6016 x 4016, 4512 x 3008, 3008 x 2008\\r 3936 x 2624, 2944 x 1968, 1968 x 1312\\r 6016 x 3376, 4512 x 2528, 3008 x 1688\\r 3936 x 2224, 2944 x 1664, 1968 x 1112
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Contrast Detection Auto Focus, Multi Point Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2250, 2500, 3200, 4000, 5000, 6400
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	0.005 s
Power source type	Battery
Video resolutions	1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	MOV
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	1280x720@25fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps
Audio formats supported	LPCM
Memory slots	2
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Display diagonal	3.2 \
Display resolution (numeric)	921000 pixels
Magnification	0.7 x
Viewfinder type	Optical
USB version	2.0
Headphone outputs	1
HDMI connector type	Mini
Product color	Black
Eye relief	21 mm
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Direct sunlight, Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade
Camera playback	Highlights, Movie, Single image, Slide show
Self-timer delay	2, 5, 10, 20 s
Camera file system	DPOF, DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-3 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL15
Operating temperature (T-T)	0 - 40 °C
Cables included	USB

Weight and Dimensions

Depth	82 mm
Width	141 mm
Height	113 mm
Weight	760 g
Weight (including battery)	850 g
