Nikon D610 User Manual

51
x
Focusing in Live View
To focus using autofocus, rotate the focus-mode
selector to AF and follow the steps below to choose
autofocus and AF-area modes.
For information on
focusing manually, see page 55.
❚❚ Choosing a Focus Mode
The following autofocus modes are available in live view:
To choose an autofocus mode, press the AF-mode button and rotate the main
command dial until the desired mode is displayed in the monitor.
Mode Description
AF-S
Single-servo AF: For stationary subjects. Focus locks when shutter-release button is
pressed halfway.
AF-F
Full-time servo AF: For moving subjects. Camera focuses continuously until shutter-
release button is pressed. Focus locks when shutter-release button is pressed halfway.
AF-mode button Main command
dial
Monitor
D Using Autofocus in Live View
Use an AF-S lens. The desired results may not be achieved with other lenses or
teleconverters. Note that in live view, autofocus is slower and the monitor may brighten or
darken while the camera focuses. The focus point may sometimes be displayed in green
when the camera is unable to focus. The camera may be unable to focus in the following
situations:
• The subject contains lines parallel to the long edge of the frame
• The subject lacks contrast
• The subject in the focus point contains areas of sharply contrasting brightness, or includes
spot lighting or a neon sign or other light source that changes in brightness
• Flicker or banding appears under fluorescent, mercury-vapor, sodium-vapor, or similar
lighting
• A cross (star) filter or other special filter is used
• The subject appears smaller than the focus point
• The subject is dominated by regular geometric patterns (e.g., blinds or a row of windows
in a skyscraper)
• The subject is moving
Focus-mode selector

Nikon D610 Specifications

General

Megapixel	24.3 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.7 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4016 pixels
Image sensor size (W x H)	35.9 x 24 mm
Still image resolution(s)	6016 x 4016, 4512 x 3008, 3008 x 2008\\r 3936 x 2624, 2944 x 1968, 1968 x 1312\\r 6016 x 3376, 4512 x 2528, 3008 x 1688\\r 3936 x 2224, 2944 x 1664, 1968 x 1112
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Contrast Detection Auto Focus, Multi Point Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2250, 2500, 3200, 4000, 5000, 6400
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	0.005 s
Power source type	Battery
Video resolutions	1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	MOV
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	1280x720@25fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps
Audio formats supported	LPCM
Memory slots	2
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Display diagonal	3.2 \
Display resolution (numeric)	921000 pixels
Magnification	0.7 x
Viewfinder type	Optical
USB version	2.0
Headphone outputs	1
HDMI connector type	Mini
Product color	Black
Eye relief	21 mm
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Direct sunlight, Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade
Camera playback	Highlights, Movie, Single image, Slide show
Self-timer delay	2, 5, 10, 20 s
Camera file system	DPOF, DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-3 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL15
Operating temperature (T-T)	0 - 40 °C
Cables included	USB

Weight and Dimensions

Depth	82 mm
Width	141 mm
Height	113 mm
Weight	760 g
Weight (including battery)	850 g
