❚❚ Manual Cleaning
If foreign matter can not be removed from the low-pass filter using the Clean image
sensor option in the setup menu (0 301), the filter can be cleaned manually as
described below.
Note, however, that the filter is extremely delicate and easily
damaged.
Nikon recommends that the filter be cleaned only by Nikon-authorized
service personnel.
1 Charge the battery or connect an AC adapter.
A reliable power source is required when inspecting or cleaning the low-pass
filter.
Turn the camera off and insert a fully-charged EN-EL15 battery or connect
an optional EP-5B power connector and EH-5b AC adapter.
The Lock mirror up
for cleaning option is only available in the setup menu at battery levels over
J.
2 Remove the lens.
Turn the camera off and remove the lens.
3 Select Lock mirror up for cleaning.
Turn the camera on and press the G
button to display the menus.
Highlight Lock
mirror up for cleaning in the setup menu
and press 2.
4 Press J.
The message shown at right will be
displayed in the monitor and a row of dashes
will appear in the control panel and
viewfinder.
To restore normal operation
without inspecting the low-pass filter, turn
the camera off.
G button

Nikon D610 Specifications

General

Megapixel	24.3 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.7 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4016 pixels
Image sensor size (W x H)	35.9 x 24 mm
Still image resolution(s)	6016 x 4016, 4512 x 3008, 3008 x 2008\\r 3936 x 2624, 2944 x 1968, 1968 x 1312\\r 6016 x 3376, 4512 x 2528, 3008 x 1688\\r 3936 x 2224, 2944 x 1664, 1968 x 1112
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Contrast Detection Auto Focus, Multi Point Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2250, 2500, 3200, 4000, 5000, 6400
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	0.005 s
Power source type	Battery
Video resolutions	1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	MOV
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	1280x720@25fps, 1280x720@50fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps
Audio formats supported	LPCM
Memory slots	2
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Maximum memory card size	64 GB
Display diagonal	3.2 \
Display resolution (numeric)	921000 pixels
Magnification	0.7 x
Viewfinder type	Optical
USB version	2.0
Headphone outputs	1
HDMI connector type	Mini
Product color	Black
Eye relief	21 mm
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Direct sunlight, Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade
Camera playback	Highlights, Movie, Single image, Slide show
Self-timer delay	2, 5, 10, 20 s
Camera file system	DPOF, DCF 2.0, Exif 2.3
Diopter adjustment (D-D)	-3 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL15
Operating temperature (T-T)	0 - 40 °C
Cables included	USB

Weight and Dimensions

Depth	82 mm
Width	141 mm
Height	113 mm
Weight	760 g
Weight (including battery)	850 g
