Nokia 7368 ISAM ONT E-240W-A User Manual

Configure an E-240W-A indoor ONT
110
7368 ISAM ONT E-240W-A Product Guide
3FE-46974-AAAA-TCZZA Issue: 01
4 Configure the parental control policy.
5 Click Enable to activate the policy.
6 STOP. This procedure is complete.
Procedure 32 DMZ and ALG configuration
1 Select Security > DMZ and ALG from the top-level menu in the EPON Home Gateway
window, as shown in Figure 48.
Figure 48 DMZ and ALG window
Table 34 describes the fields in the DMZ and ALG window.
Table 34 DMZ and ALG parameters
Field Description
ALG Config Select the checkboxes to enable the protocols to be supported by the ALG: FTP,
SIP, H323, RTSP, L2TP, IPSEC, PPTP
DMZ Config
WAN Connection List Choose a WAN connection from the drop-down menu
Enable DMZ Select this checkbox to enable DMZ on the chosen WAN connection
DMZ IP Address Choose Customer Setting and enter the DMZ IP address or choose the IP address
of a connected device from the drop-down menu
Release 06.00.00h | January 2019 | Edition 08

Nokia 7368 ISAM ONT E-240W-A Specifications

General

Brand	Nokia
Model	7368 ISAM ONT E-240W-A
Category	Network Hardware
Language	English
