7368 ISAM ONT E-240W-A Product Guide Configure an E-240W-A indoor ONT
Issue: 01 3FE-46974-AAAA-TCZZA 111
2 Configure ALG.
3 Click Save ALG.
4 Configure DMZ.
5 Click Save DMZ.
6 STOP. This procedure is complete.
Procedure 33 Access control configuration
This procedure describes how to configure the access control level (ACL).
1 Select Security > Access Control from the top-level menu in the EPON Home Gateway
window, as shown in Figure 49.
Figure 49 Access Control window
Note 1 — ACL takes precedence over the firewall policy.
Note 2 — The trusted network object will be shared for all WAN
connections; it is not applied individually to a WAN connection.
Release 06.00.00h | January 2019 | Edition 08
