7368 ISAM ONT E-240W-A Product Guide Install an E-240W-A indoor ONT
Issue: 01 3FE-46974-AAAA-TCZZA 53
5.6 Procedure
Use this procedure to install an E-240W-A indoor ONT.
1 Place the indoor ONT unit:
a On the flat surface, such as a desk; go to step 3.
b On a wall, go to step 2.
2 Mount the E-240W-A indoor ONT on a wall.
The E-240W-A indoor ONT must be mounted in a horizontal position, as indicated by the wall
mounting key holes in Figure 14.
If possible, mount the ONT on a wall stud.
Figure 14 shows the ONT with the connections and the key mounting holes.
Note — The E-240W-A cannot be stacked with another ONT or with
other equipment. The ONT mounting requirements are:
• allow a minimum 100 mm clearance above the top cover
• allow a minimum 50 mm clearance from the side vents
• do not place any heat source directly above the top cover or below the
bottom cover
Release 06.00.00h | January 2019 | Edition 08
