Nokia 7368 ISAM ONT E-240W-A User Manual

7368 ISAM ONT E-240W-A Product Guide E-240W-A unit data sheet
Issue: 01 3FE-46974-AAAA-TCZZA 41
Figure 10 E-240W-A ONT fiber optic connection
Figure 11 shows the E-240W-A ONT with the fiber cover
Figure 11 E-240W-A ONT with fiber cover
Table 5 describes the physical connections for E-240W-A indoor ONTs.
25273
ON/OFFPOWER
USB2USB1LAN4LAN3LAN2LAN1
TEL1 TEL2
WLAN
RESET
WPS2.4G
WPS5G
Fiber optic connector
(without cover)
25274
ON/OFFPOWER
USB2USB1LAN4LAN3LAN2LAN1
TEL1 TEL2
WLAN
RESET
WPS2.4G
WPS5G
Fiber optic connector
(covered)
Release 06.00.00h | January 2019 | Edition 08

Nokia 7368 ISAM ONT E-240W-A Specifications

General

Brand	Nokia
Model	7368 ISAM ONT E-240W-A
Category	Network Hardware
Language	English
