7368 ISAM ONT E-240W-A Product Guide Configure an E-240W-A indoor ONT
Issue: 01 3FE-46974-AAAA-TCZZA 129
Procedure 47 Diagnose WAN connections
1 Select Maintenance > Diagnostics from the top-level menu in the EPON Home Gateway
window, as shown in Figure 63.
Figure 63 Diagnostics window
2 Choose a WAN connection to diagnose from the drop-down menu.
3 Enter the IP address or domain name.
4 Select the test type: ping, traceroute, or both.
5 Enter the number of ping attempts to perform (1 - 1000); the default is 4.
6 Enter a ping packet length (64-1024); the default is 64.
7 Enter the maximum number of trace hops (1-255); the default is 30.
8 Click Start Test. Results will be displayed at the bottom of the window.
Release 06.00.00h | January 2019 | Edition 08
