RADIUS Attributes Reference
62
RADIUS ATTRIBUTES REFERENCE GUIDE
RELEASE 14.0.R4
3HE 10793 AAAB TQZZA 01 Issue: 01
2.2.3 Wholesale-Retail — L2TP Tunneled Access Mode
Table 7 Wholesale-Retail: Local Access Mode (Applicability)
Attribute ID Attribute Name Access
Request
Access Accept CoA Request
26-6527-17 Alc-Retail-Serv-Id 0 0-1 0-1
26-6527-31 Alc-MSAP-Serv-Id 0 0-1 0
26-6527-32 Alc-MSAP-Policy 0 0-1 0
26-6527-33 Alc-MSAP-Interface 0 0-1 0
Table 8 Wholesale-Retail: L2TP Tunneled Access Mode (Description)
Attribute ID Attribute Name Description
64 Tunnel-Type The tunneling protocol(s) to be used (in the case of a tunnel
initiator) or the tunneling protocol in use (in the case of a tunnel
terminator). This attribute is mandatory on LAC Access-Accept
and needs to be L2TP. The same attribute is included on LNS
in the Access-Request and Acct-Request if the CLI RADIUS
policy include-radius-attribute tunnel-server-attrs is
enabled on a 7750 SR LNS. For L2TP Tunnel/Link Accounting
this attribute is always included on LAC and LNS.
65 Tunnel-Medium-Type The transport medium to use when creating a tunnel for those
protocols (such as L2TP) that can operate over multiple
transports. This attribute is mandatory on LAC Access-Accept
and needs to be IP or 'IPv4.The same attribute is included on
LNS in the Access-Request and Acct-Request if the CLI
RADIUS policy include-radius-attribute tunnel-server-attrs
is enabled on a 7750 SR LNS. For L2TP Tunnel/Link
Accounting this attribute is always included on LAC and LNS.
66 Tunnel-Client-Endpoint The dotted-decimal IP address of the initiator end of the tunnel.
Preconfigured values are used when attribute is omitted
(configure router/service vprn service-id l2tp local-
address). If omitted in Access Accept on LAC and no local-
address configured, then the address is taken from the
interface with name system. This attribute is included on LNS in
the Access-Request and Acct-Request only if the CLI RADIUS
policy include-radius-attribute tunnel-server-attrs is
enabled on a 7750 SR LNS. For L2TP Tunnel/Link Accounting
this attribute is always included on LAC and LNS as untagged.
