RADIUS ATTRIBUTES REFERENCE GUIDE
RELEASE 14.0.R4
3HE 10793 AAAB TQZZA 01 Issue: 01
2.2.6.1 IP Filter Attribute Details
[92] Nas-Filter-Rule and [26-6527-158] Alc-Nas-Filter-Rule-Shared
The format for [92] Nas-Filter-Rule and [26-6527-158] Alc-Nas-Filter-Rule-Shared is
a string formatted as: action direction protocol from source to destination options.
Table 20 provides details on the respective fields.
26-6527-159 Alc-Ascend-Data-
Filter-Host-Spec
octets max. 10 attributes per
message or max. 10 filter
entries per message.
min. length 22 bytes
(IPv4), 46 bytes (IPv6)
max. length: 110 bytes
(IPv4), 140 bytes (IPv6)
A string of octets with fixed field
length (type (ipv4/ipv6), direction
(ingress/egress), src-ip, dst-ip,...).
Each attribute represents a single
filter entry. See IP Filter Attribute
Details for a description of the
format.
Example: # permit in ip from any to
10.1.1.1/32
Alc-Ascend-Data-Filter-Host-Spec
=
0x01010100000000000a0101010
0200000000000000000
Table 18 IP and IPv6 Filters (Limits) (Continued)
Attribute ID Attribute Name Type Limits SR OS Format
Table 19 IP and IPv6 Filters (Applicability)
Attribute ID Attribute Name Access
Request
Access
Accept
CoA
Request
92 NAS-Filter-Rule 0 0+ 0+
26-529-242 Ascend-Data-Filter 0 0+ 0+
26-6527-134 Alc-Subscriber-Filter 0 0-1 0-1
26-6527-158 Alc-Nas-Filter-Rule-Shared 0 0+ 0+
26-6527-159 Alc-Ascend-Data-Filter-Host-Spec 0 0+ 0+
