User Guide Introduction
3TG-02285-AAAA-TCZZA-02 © 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
9
• mounted on a window (either outside or inside; uses a mounting sleeve)
• placed close to the inside of a window (uses a desktop stand)
Kit contents can include the following, but note that contents vary by kit:
• FastMile 5G Receiver, with a pre-attached PoE cable (the length and type of
cable depends on the kit)
• cable clamp
• PoE injector (indoor use only)
• PoE cable (provided in kits primarily intended for outside window applications)
• PoE injector AC cable
• Either of the following
- mounting sleeve (has a side with four adhesive strips for attaching to the
window)
- desktop stand
• Cleaning wipes (wet and dry; window mount only)
• Quick onboarding guide (a sticker that has a QR code, username and password,
and a Bluetooth PIN code, along with quick steps for onboarding)
• Quick Start Guide
• Safety and warranty cards, including leaflet that has cabling installation safety
guidelines
Physical interfaces
Physical interfaces for the FastMile 5G Receiver are located on the front, back, and
bottom of the device.
The front of the device has a multicolor LED that indicates status and signal strength
(it is synchronized with the LED on the back of the device). The LED is described in
detail in Understanding the LED colors.
Note: Some kits may include an Ethernet LAN cable that you can use to connect the PoE
injector to the 1 Gbps Ethernet LAN port of your gateway.
You will need to provide an Ethernet LAN cable if it is not included in your kit.
