Nokia N93i User Manual

Copyright © 2007 Nokia. All rights reserved.
Camera
18
The self-timer indicator ( ) blinks and the device beeps
when the timer is running. The camera takes the picture
after the selected delay elapses.
You can also use the self-timer in the sequence mode.
Tip! Select Options > Self timer > 2 seconds to
keep your hand steady when taking a picture.
Flash
The flash is available only in the main camera.
Keep a safe distance when using the flash. Do not use the
flash on people or animals at close range. Do not cover the
flash while taking a picture.
The camera has an LED flash for low light conditions. The
following flash modes are available: Automatic (), On
(), and Off ().
To switch between the flash modes, press the flash key.
Setup settings — color and lighting
To enable the camera to reproduce colors and lighting
more accurately or to add effects to your pictures or
videos, scroll through the toolbar, and select from the
following options:
Shooting mode — Select a proper shooting mode for the
environment in which you take pictures. Every shooting
mode uses its own lighting settings that have been
adjusted according to a certain kind of environment.
White balance — Select the current lighting condition
from the list. This allows the camera to reproduce colors
more accurately.
Exposure value (images only) — Adjust the exposure time
of the camera.
Colour tone — Select a color effect from the list.
The screen display changes to match any settings you
make so you see how the change affects the pictures or
videos.
The available settings vary depending on the selected
camera.
The setup settings are camera specific; if you change the
settings in the secondary camera, the settings in the main
camera do not change. The setup settings do, however,
transfer between the image and video modes. The setup
settings return to the default settings when you close the
camera.
Shooting modes
A shooting mode helps you to find the right color and
lighting settings for the current environment. Select a
proper shooting mode for taking pictures or recording
video clips from the shooting mode list. The settings of

Nokia N93i Specifications

General

Display resolution	240 x 320 pixels
Display number of colors	16.78 million colors
Internal memory	50 MB
Compatible memory cards	MiniSd
Rear camera flash	No
Rear camera resolution	2048 x 1536 pixels
Video capture resolution (max)	640 x 480 pixels
USB 2.0 ports quantity	1
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Ringer type	Polyphonic
Talk time (2G)	3.9 h
Battery capacity	950 mAh
Standby time (2G)	283.2 h
Form factor	Clamshell
2G standards	EDGE, GPRS
Data network	wcdma
Bluetooth version	2.0+EDR
Specific absorption rate (SAR) value (EU)	0.84 . W/kg

Weight and Dimensions

Depth	25 mm
Width	58 mm
Height	108 mm
Weight	163 g
