Nordson 3100V Series User Manual

Installation
A1-18
E 2000 Nordson Corporation
All rights reserved
41-3000V
Issued 5/00
A3EN-04-[3V-A-AAXP]-12
If your unit has a triggering solenoid valve on the pump, follow this
procedure to connect a 24 VDC triggering device to the center frame
terminal block. See Figure A 1-12 to determine whether your pump has a
triggering solenoid valve (1). If your pump does not have this valve, skip
to the next procedure, Connecting Output Contacts (Optional).
4130879A
1
2
3
4
1
2
3
4
2
3
Fig. A 1 -12 Connecting a Triggering Device for the Pump Solenoid Valve
1. Triggering s olenoid valve
2. Center frame terminal block
3. Wires from 24 VDC triggering
device
4. Strain relief
